Massenza MI5 Geotechnical Drill Rig

Description

Used Massenza MI5 Geotechnical Drill Rig for sale.

1,500 Hours

Drill head model TM6CL2

Steel body

Crown-pinion transmission, shafts and gears made of hardened alloy steel,

Mounted on bearings, greased in an oil bath.

Powered by two hydraulic motors.

Floating and damped drive shaft, made of moulded rubber with internal steel reinforcements, 50 mm free internal passage.

1st gear: Torque 10,164 Nm, Speed at 50 rpm

2nd gear: Torque 5,820 Nm, Speed at 75 rpm

3rd gear: Torque 4,370 Nm, Speed at 100 rpm

4th gear: Torque 2,910 Nm, Speed at 150 rpm

Clamps-177Kn

Main winch-23Kn

Pull down/Pull up-64kn

Max depth-150m

Weight: 6,500kg
