Soilmec CM-48 CFA Piling Rig

Description

Used Soilmec CM-48 CFA Piling Rig for sale.

Rig has had a new engine in 2011 and done 1,300 hours since (new Iveco 6-cylinder engine)

Rebuilt track chain

Maximum Pile Depth: 19.5m ( +4 Flight Extension )

Maximum Pile Diameter: 900mm

Maximum Torque: 90kNm

Maximum Nominal Pull Main Winch: 102kN

Maximum Nominal Pull Service Winch: 41kN

Maximum Rotary Table Pull: 8850kN

Drilling Speed: 31.4rpm

Undercarriage Total Length: 4700mm

Undercarriage Shoe Width: 700-900mm

Total Width Open: 4000-4200mm

Total Width Closed: 2500-2900mm

Working Weight: 38ton
